5,000 Dwelling Unit Neighborhood
Conceptual Competition for the Design of a 5,000 Dwelling-Unit Neighborhood – First Prize for High Density
We conceived a 200-acre area with one-third of it devoted to parks. The neighborhood is seen as a totally pedestrian area, with distances not exceeding 15-minute walking from the center. The eccentricity of the linear center allows a better relationship between the new quarter, existing urban structures and future development. The through-traffic encircles the are without ever penetrating it. Parking structures are located along the freeway ring, which also serve as stations for a monorail and conveyors entering the neighborhood.
High-density residences are located within the central space and medium-density residences extend out from this center. The towers fulfill urban functions such as offices, commerce, entertainment and hotels. The central space with public facilities and spaces is “shadowed” by penthouse-like condominiums with total flexibility of assemblage . Additional condominiums are located in higher floors.
The project is though to built with prefabricated components that are interchangeable.
